Quick-Fit Sealed (QFS) Pressed Bend, 15 degree

Quick-Fit Sealed (QFS) Pressed Bend, 15 degree
Quick-Fit Sealed (QFS) Pressed Bend, 15 degree

A QF clamp-together duct component with caulked seams to provide protection against leakage where sealed systems are needed. Ø80 - 315 mm, galvanised steel construction.

  • Allows airflow direction change in a run of a duct. Manufactured with added caulked seams to provide protection against leakage, ideal for oil mist applications.

  • Quick and easy to install thanks to rolled edges and a leak-tight clamping system.

  • Reusable and easy to relocate - a cost-effective, sustainable choice for evolving production needs.

  • Manufactured to ISO 9001 quality and ISO 14001 environmental management standards.

  • Engineered to comply with SMACNA G90 gauge and Class 3 pressure standards for reliable performance.

Contact us
Product Details
Products
Documents (0)
Models (0)
Video (0)

Nordfab's Quick-Fit Sealed (QFS) pressed bends (15°), allow airflow direction change in a run of a duct. They are designed as our Standard QF Pressed Bends, with Quick-Fit rolled ends, but have added caulked seams to provide protection against leakage. QFS Pressed Bends are available in galvanised steel construction, ranging from 80 mm to 315 mm in diameter. The QFS Pressed Bends come in 90°, 60°, 45°, 30°, and 15° to ensure efficient airflow.

Quick-Fit Sealed (QFS) Ducting
Designed for machining and any other operations which create oil mists, Nordfab Quick-Fit Sealed (QFS) Ducting can significantly reduce risks of leakage from ducting. QFS features laser welded and caulked duct (solid seams eliminate leakage) and double sealing at duct connections. All bends, branches, reducers, and other products with joints or collars are epoxy caulked. When clipping the ductwork together, an additional nitrile gasket is placed between the parts to avoid leakage. The QFS clamp features a generously dimensioned sealing gasket held firmly in place by positive over-centre clamping action over the rolled collars at the duct ends to be joined. For added security, a locking pin may be inserted.

The world's fastest ducting
For most dust and fume collection requirements and applications, Nordfab Quick-Fit Sealed (QFS) modular clamp-together ducting is a crucial component of dust collection, fume extraction, and process ventilation systems. It has the capability to significantly reduce installation time by up to 50%, resulting in cost savings and reduced downtime.

Easy to install
Quick-Fit Sealed is easy and quick to install, designed for effortless cleaning, and can be reused when adjusting facility layouts, providing one of the lowest life-cycle costs of any ducting product. The Quick-Fit rolled edges allow quick and easy connections with the Quick-Fit Sealed clamp when installing, extending, or taking apart runs of duct.
